Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 248

Ctrl Command control_command
(05
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
) Code Returned Data Signal Type
H L
34 Sensor board operating temperature
H
Bits #4...19
Bits #0...3
35 Emerging-beam-opening temperature
H
Bits #4...19
Bits #0...3
36 Temperature of mirror 2
H
Bits #4...19
Bits #0...3
37 Temperature of mirror 1
H
Bits #4...19
Bits #0...3
38 Protective-window temperature
H
Bits #4...19
Bits #0...3
39 Collimator temperature
H
Bits #4...19
Bits #0...3
3A Galvanometer-mount temperature
H
Bits #4...19
Bits #0...3
3B Coolant-flow rate
H
Bits #4...19
Bits #0...3
3C Protective-window scattered light value
H
Bits #4...19
Bits #0...3
3D Flags sensor board
H
(*)
if "1" then an INTERLOCK error is initiated
Bit #19 (MSB)
Bit #18
Bit #17
(*)
Bit #14
Bit #7
Bit #6
(*)
Bit #5
(*)
Bit #4
Bits #0...3
3F Position value scale factor setting (as of Firmware Version 2072)
H
Bits #6...19
Bits #4, 5
Bits #0...3
Operating temperature / 0.1°C [0 ... 65535]
= 0
Temperature / 0.05°C [0 ... 2250]
= 0
(Temperature + 26.6°C) / 0.05°C [0 ... 2250]
= 0
(Temperature + 26.6°C) / 0.05°C [0 ... 2250]
= 0
Temperature / 0.044°C [0 ... 2250]
= 0
Temperature / 0.05°C [0 ... 2250]
= 0
Temperature / 0.05°C [0 ... 2250]
= 0
-1
(Coolant-flow rate + 5.51 l·min ) / (0.00595 l·min
(for T=20°C and a flow rate larger than 3 l·min
= 0
-3
Scattered light value / 10 V [0 ... 2250]
= 0
= 1: Protective-window temperature value not in [0 ... 1882]
= 1: Temperature of mirror 1 value not in [0 ... 2250]
= 1: Temperature of mirror 2 value not in [0 ... 2250]
= 1: Emerging-beam-opening temperature value not in [0 ... 1200]
= 1: Protective-window scattered light value not in [0 ... 2250]
= 1: Coolant-flow rate value not in [750 ... 2250]
= 1: Galvanometer-mount temperature value not in [0 ... 1600]
= 1: Collimator temperature value not in [0 ... 2000]
= 0
Reserved
n
Scale factor = 1/2 with n = 2 · bit #5 + bit #4
= 0
-1
) [0 ... 2250]
-1
)
