Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 439

Ctrl Command set_jump_speed_ctrl
Function same as
Call
set_jump_speed_ctrl( Speed )
Parameter
Speed
Comments • The command will be ignored
BUSY status is currently set (list is being processed or has been halted via pause_list).
In contrast, the command is executed when a list has been paused via
(PAUSED status set) or the board's INTERNAL-BUSY status is currently set.
® ®
RTC 4 RTC 5 new command
®
In RTC 4 compatibility mode: as
References set_jump_speed, set_mark_speed,
Control set_jump_table
Command
Function reads the jump delay table with 1024 unsigned 16-bit values stored at the supplied PC
address and loads them onto the board as the jump delay table (see notes for
get_jump_table).
Call
ErrorCode = set_jump_table( Addr )
Parameters
Addr
Return Error code as an unsigned 32-bit value:
0
1
4
11
Notes • The command set_jump_table will not execute
RTC5_BUSY) if the board's BUSY status is currently set (list is being processed or was
paused via pause_list) or if the board's INTERNAL BUSY status is set. In contrast, the
command will execute if a list was paused via
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 525
Reference get_jump_table,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
set_jump_speed (see above), but a control command
jump speed in bits per ms (as a 64-bit IEEE floating point value)
Allowed range: [1.6 ... 800000.0]
(get_last_error
set_jump_speed
PC Address of a 2048-byte area of PC main memory
no error
busy error: board BUSY or INTERNAL BUSY
verify error: DSP memory error
driver error
load_jump_table_offset
return code: RTC5_BUSY) if the board's
set_mark_speed_ctrl
(get_last_error return code: RTC5_BUSY)
(get_last_error
set_wait (PAUSED status set).
set_wait
return code:
439
