Variable set_scale_list
List Command
Function same as
Call
set_scale_list( HeadNo, Scale, at_once )
Parameters
HeadNo
Scale
at_once
® ®
RTC 4 RTC 5 new command
Version info Last change with version DLL 525, OUT 527: behavior for at_once = 3
References set_scale
Delayed Short set_scanner_delays
List Command
Function sets the scanner delays
Call
set_scanner_delays( Jump, Mark, Polygon )
Parameters
Jump, Mark,
Polygon
Comments • Scanner delays are described in the chapter
• Variable Delays for jumps and polylines can be set via
• If necessary, the specified delays will be automatically adjusted by the RTC
laser control errors (see
® ®
RTC 4 RTC 5 unchanged functionality (except for the extended range of values)
References set_delay_mode,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
set_scale (see above), but a list command
See set_scale.
See set_scale.
This parameter (unsigned 32-bit value) determines when the defined
transformation becomes effective:
= 0: The transformation settings are only collected and intermediately
stored, but the transformation is not processed as long as this is not
activated via another coordinate transformation (e.g. via a list
command with at_once = 1 or a corresponding control command).
= 1: The transformation is immediately calculated (including all
transformation settings that were collected until then) and processed
prior to the next list command. The "laser active" laser control signals
will first be switched off if necessary.
= 2: The transformation settings are only collected and intermediately
stored (as with at_once = 0). However, The transformation is
immediately calculated (including all transformation settings that
were collected and intermediately stored until then) and applied to
the current position when the next jump_abs, jump_rel,
goto_xyz command is executed.
= 3: As with at_once = 1, but the laser control signals remain unaffected.
> 3: See at_once = 2
scanner delays as unsigned 32-bit values.
1 bit equals 10 µs. Allowed range: [0...(2
"Automatic Delay Adjustments" on page
set_laser_delays
32
–1)]
"Scanner Delays" on page 100.
set_delay_mode (page
107).
goto_xy or
415).
®
5 to avoid
