Ctrl Command get_value
Example Querying diverse data types (primary scan head connector, X axis)
(C/C++)
a) XY2-100 status word, PowerOK status
UINT statusword, powerOK;
control_command (1, 1, 0x0500); // only applicable for iDRIVE
statusword = (get_value(1) & 0x000FFFF0) >> 4;
powerOK = (statusword & 0x00000080);
b) Serial number (only applicable for iDRIVE
UINT SN_low, SN_high, SN;
// the serial number's lower 16 bits are selected for return
// and queried via get_value:
control_command (1, 1, 0x051E);
SN_low = (get_value(1) & 0x000FFFF0)>>4;
// the serial number's upper 16 bits are selected for return
// and queried via get_value:
control_command (1, 1, 0x051F);
SN_high = (get_value(1) & 0x000FFFF0)>>4;
//Complete serial number:
SN = (SN_high << 16) + SN_low;
c) Actual position (only applicable for iDRIVE
long real_position;
control_command (1, 1, 0x0501);
real_position = get_value(1);
® ®
RTC 4 RTC 5 essentially unchanged functionality, however:
Even in RTC
get transferred to the PC as 32-bit data. Therefore, you must evaluate the values
accordingly (see above).
Version info Last change (with version DLL 536, OUT 536): Additional selectable data signals (Signal =
43 and 44, see set_trigger).
References get_values, set_trigger, get_waveform,
®
