J5
MASTER
Legend
Master . . . . . . 6-pin MASTER connector (see
JP1 . . . . . . . . . Jumper for selecting the output signal level at the MULTI connector (see
JP2 - JP8 . . . . . Jumpers for configuring Pin B40 and B42 of the MULTI connector (see
JP10+JP12 . . . Jumpers for setting how the 10 V maximum output voltage is generated at the
analog outputs ANALOG OUT1 and ANALOG OUT2 on the MULTI connector (see
page 585)
JP17+JP18 . . . Jumpers for setting the binary stack address, i.e. for electrical configuration of the
board for its position in the stack (see
®
Layout of the RTC 5 PC/104-Plus board (back side)
®
RTC 5 PC Interface Board
Rev. 1.9 e
®
15 Appendix A: The RTC 5 PC/104-Plus Board
JP7 JP5
JP8 JP6
JP4 JP3
JP2
JP17
"Master/Slave Synchronization", page
page
JP1
1
JP18
JP12
1
JP10
1
579)
584)
page 586)
page 586)
