Ctrl Command set_offset_xyz
® ®
RTC 4 RTC 5 new command
With the RTC
values. In RTC
®
RTC 4) and the RTC
the Z axis) by 16 (the permissible range of values is correspondingly reduced to
[–32768 ... +32767]).
Version info Last changes:
• With version DLL 525, OUT 527: behavior for at_once = 3
• With Version DLL 536, OUT 536: HeadNo = 4
References set_offset_xyz_list, set_offset, set_angle, set_matrix, set_scale,
Variable set_offset_xyz_list
List Command
Function same as
Call
set_offset_xyz_list( HeadNo, XOffset, YOffset, ZOffset, at_once )
Parameters
HeadNo
XOffset,
YOffset
at_once
® ®
RTC 4 RTC 5 See set_offset_xyz.
Version info Last change with version DLL 525, OUT 527: behavior for at_once = 3
References set_offset_xyz, set_offset_list,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
®
5, the image field coordinates for the X and Y axes are specified as 20-bit
®
4 compatibility mode, they are specified as 16-bit values (as with the
®
5 multiplies the specified offset values for the X and Y axes (not for
set_offset_xyz (see above), but a list command
See set_offset_xyz.
See set_offset_xyz.
This parameter (unsigned 32-bit value) determines when the defined
transformation becomes effective:
= 0: The transformation settings are only collected and intermediately
stored, but the transformation is not processed as long as this is not
activated via another coordinate transformation (e.g. via a list
command with at_once = 1 or a corresponding control command).
= 1: The transformation is immediately calculated (including all
transformation settings that were collected until then) and processed
prior to the next list command. The "laser active" laser control signals
will first be switched off if necessary.
= 2: The transformation settings are only collected and intermediately
stored (as with at_once = 0). However, The transformation is
immediately calculated (including all transformation settings that
were collected and intermediately stored until then) and applied to
the current position when the next jump_abs, jump_rel,
goto_xyz command is executed.
= 3: As with at_once = 1, but the laser control signals remain unaffected.
> 3: See at_once = 2
set_defocus_list
set_defocus
goto_xy or
