Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 523

Ctrl Command stop_execution
Function stops execution of the list and deactivates the "laser active" laser control signals
immediately
Call
stop_execution()
Comments • With versions OUT 534 and lower, the command is only executed if a list is BUSY or
PAUSED (else
stop_execution deactivates the "laser active" laser control signals even if no list is
active (here the command has no other effects; here too:
RTC5_BUSY).
• With stop_execution, the mirrors will stay in the current position, unless a home jump
has been previously defined via
will be executed). Therefore, before a new list is loaded, the mirrors should be set to a
defined position using the command goto_xy.
• The external START inputs are disabled (see
• The Processing-on-the-fly correction is turned off (Processing-on-the-fly option only).
• The BUSY list status values (see read_status) and the BUSY list execution status value
(see get_status) are reset.
• A list that was interrupted with stop_execution cannot be resumed and must instead
be newly started (e.g. via execute_list_pos). To only temporarily halt a list and later
resume it, you can use the commands
• stop_execution only affects the addressed RTC
it will not be passed on to the downstream slave boards. If all boards of a master/slave
chain shall be synchronously stopped, then
signal must be applied to the master board (also see
® ®
RTC 4 RTC 5 unchanged
Version info Last change with version OUT 535 (see comment)
References get_startstop_info
Ctrl Command stop_list
Function pauses execution of the list and deactivates the "laser active" laser control signals.
Call
stop_list()
• The command stop_list is synonymous with
Comments
tion there.
® ®
RTC 4 RTC 5 essentially unchanged functionality, however:
®
the RTC
References pause_list
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
get_last_error return code: RTC5_BUSY). As of Version OUT 535, however,
home_position
5 also has a PAUSED status that will be set via stop_list.
get_last_error
or home_position_xyz
"External List Start", page
pause_list or stop_list.
®
5 board. Even in a master/slave chain,
simulate_ext_stop or an external stop
page 84).
pause_list (page 382)
return code:
(a home jump
210).
– see the informa-
523
