Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 338

Ctrl Command load_position_control
Function loads a table with data points from an ASCII text file and determines – via linear
interpolation – the scaling function for position-dependent laser control (radial correction,
see page
Call
NoOfDataPoints = load_position_control( Name, No )
Parameters
Name
No
Result signed 32-bit value (a positive error code in case of an error, the negative number of found
data points in case of success):
Value
– 1 to – 50
–256
1
3
4
5
8
11
13
Comments • The format requirements for the text file's table entries with data points for position-
dependent laser control are described in
page
range of control values.
• The command load_position_control overwrites any previously loaded scaling func-
tion for position-dependent laser control.
• For Name = 0 (as during initialization via load_program_file), the scaling function
Scale(Position)=1.0 is loaded for the complete position range so that no position-
dependent correction takes place.
• Position-dependent laser control only takes effect during subsequent mark or arc
commands if it was initialized via set_auto_laser_control. Position-dependent laser
control is deactivated via
Scale(Position)=1.0. Also see
• The load_position_control command will not be executed
code: RTC5_BUSY) if the board's BUSY status is currently set (list is being processed or
has been halted via pause_list) or the board's INTERNAL-BUSY status is currently set. In
contrast, the command is executed when a list has been paused via
status set).
• During execution of load_position_control, external starts will be suppressed.
• Before loading a table, load_position_control performs a DSP memory check. In case
of an error, error code 4 is returned.
® ®
