Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 371

Normal para_jump_abs
List Command
Function moves the output point (of the laser focus) along a 2D vector at jump speed from the
current position to the specified position (absolute coordinate values) within a two-
dimensional image field and, simultaneously as well as linearly, changes the signal
parameter selected via
Call
para_jump_abs( X, Y, P )
Parameters
X, Y
P
Comments • If vector-defined laser control has not been previously activated via set_vector_control,
then para_jump_abs will behave like
P will then be ignored.
• If vector-defined laser control is activated, then simultaneously with the motion of the
output point of the laser focus the signal parameter selected via
will be linearly varied from the last valid value to P (see
page
• There is no abs mechanism for P. P will, if necessary, be clipped to the maximum allowed
value.
• If para_jump_abs is used along with position- and/or speed-dependent laser control
for the same control parameter, then the current value of P will be used as the basis of
the 100% value for laser control (see
® ®
RTC 4 RTC 5 new command
®
In RTC 4 compatibility mode, the RTC
(the permissible range of values is correspondingly reduced).
The parameter P does not have a RTC
must be used.
References jump_abs, set_vector_control, para_jump_abs_3d,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
set_vector_control
absolute coordinates of the jump vector end point in bits as signed 32-bit
values; allowed range: [–8388608 ... 8388607] (out-of-range values will be
edge-clipped). The complete value range [–8388608 ... 8388607] is only
usable as a virtual image field e.g. for (enabled) Processing-on-the-fly
applications. The current coordinates will be clipped to [–524288 ... 524287]
(real image field size) during runtime directly prior to use of the correction
table.
End value of the signal parameter as an unsigned 32-bit value; allowed range:
dependent on the selection made via
identical with set_vector_control
147).
to the specified value.
set_vector_control
(Value parameter)
jump_abs (see comments there). The parameter
"Vector-Defined Laser Control",
"Vector-Defined Laser Control", page
®
5 multiplies the specified coordinate values by 16
®
4 compatibility mode. The original RTC
para_jump_rel
(Ctrl parameter),
set_vector_control
147).
®
5 units
