arc_rel

List Command
Function moves the laser focus from the current position at marking speed along an arc with the
specified angle and center point (relative coordinate values) within a two-dimensional
image field.
Call
arc_rel( dX, dY, Angle )
Parameters
dX,dY
Angle
Comments • The coordinates for the arc center are to be supplied as relative coordinates with respect
to the current position. Otherwise, the command is identical to
comments there).
• The current coordinates will be clipped to [–524288 ... 524287] (real image field size)
during runtime directly prior to use of the correction table.
® ®
RTC 4 RTC 5 unchanged functionality (except for the extended range of values).
®
In RTC 4 compatibility mode, the RTC
values by 16 (the permissible range of values is correspondingly reduced to
[–524288 ... 524287]).
References set_mark_speed, set_scanner_delays, arc_abs, timed_arc_rel, mark_rel, arc_rel_3d,
mark_ellipse_rel
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
relative coordinates of the arc center in bits as signed 32-bit value; allowed
range: [–8388608 ... 8388607] (out-of-range values will be edge-clipped).
arc angle in ° [–360.0° ... +360.0°] as 64-bit IEEE floating point value
(positive angle values correspond to clockwise angles)
®
5 multiplies the specified arc center coordinate
arc_abs (see the
234
