Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 468

Normal set_pixel_line
List Command
® ®
RTC 4 RTC 5 • On the RTC
PixelMode = 1) .
• The RTC
output mode, the RTC
port).
• For the RTC
(in contrast, for the RTC
• For the RTC
normal list commands (whereas the RTC
• In RTC
meter values will then be internally converted to 1/64 µs units (i.e. multiplied by 8). The
permissible range of values is correspondingly smaller (the smallest permissible value is
then 13). In RTC
nate values dX,dY by 16 (the permissible range of values is correspondingly reduced).
Version info Last change with version OUT 515
References set_pixel, set_n_pixel,
List Multi- set_pixel_line_3d
Command
Function activates the pixel output mode and defines various pixel output parameters.
Call
set_pixel_line_3d( Channel, HalfPeriod, dX, dY, dZ )
Parameters
Channel
HalfPeriod
dX, dY
dZ
Comments • Unlike set_pixel_line, set_pixel_line_3d lets you define the pixel spacing (between two
adjacent image points on a line) via a 3D vector.
• Unlike set_pixel_line, set_pixel_line_3d will additionally require two list-memory loca-
tions if parameter dZ is non-zero. The initial component executes as a short list
command before the primary component (a normal list command). Any still-pending
delayed short list command will get executed first.
• In other respects, set_pixel_line_3d behaves similarly to
comments there).
® ®
RTC 4 RTC 5 new command,
®
RTC 4 compatibility mode: see set_pixel_line.
Version info Available beginning with version DLL 536, OUT 536
References set_pixel_line, set_pixel,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
®
5, only one pixel mode is available (equivalent to the RTC
®
5 allows selection of the output channel (Channel) for analog signals (in pixel
®
4 can only output analog voltage levels at its ANALOG OUT2
®
5, the pixel output period is specified as the half output period HalfPeriod
®
4 it is the full output period PixelPeriod).
®
5, the command set_pixel_line requires only one list entry, as with other
®
4 compatibility mode, HalfPeriod must be specified in units of 1/8 µs. The para-
®
4 compatibility mode, the RTC
set_pixel_line_3d
See set_pixel_line (number of the analog output port).
See set_pixel_line (half pixel output period).
See set_pixel_line:
Distance in the X and Y directions between adjacent pixels in bits
(64-bit IEEE floating point values)
Distance in the Z direction between adjacent pixels in bits
(64-bit IEEE floating point values)
As with all Z-coordinates, dZ too is scaled 16x smaller than dX and dY.
set_n_pixel
®
4 requires two list entries).
®
5 also multiplies the specified coordi-
set_pixel_line
®
4's
(see the
468
