Normal para_mark_rel
List Command
Function moves the laser focus at marking speed along a 2D vector from the current position to the
specified position (relative coordinate values) within a two-dimensional image field and,
simultaneously as well as linearly, changes the signal parameter selected via
set_vector_control
Call
para_mark_rel( dX, dY, P )
Parameters
dX, dY
P
Comments • The coordinates for the mark vector's end point are to be supplied as relative coordi-
nates with respect to the current position. Otherwise, the command is identical to
para_mark_abs
• P will not be treated on a relative basis.
® ®
RTC 4 RTC 5 new command
®
In RTC 4 compatibility mode, the RTC
(the permissible range of values is correspondingly reduced).
The parameter P does not have a RTC
must be used.
References mark_rel, set_vector_control, para_mark_abs,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
to the specified value.
relative coordinates of the mark vector end point in bits as signed 32-bit
values; allowed range: [–8388608 ... 8388607] (out-of-range values will be
edge-clipped). The complete value range [–8388608 ... 8388607] is only
usable as a virtual image field e.g. for (enabled) Processing-on-the-fly
applications. The current coordinates will be clipped to [–524288 ... 524287]
(real image field size) during runtime directly prior to use of the correction
table.
End value of the signal parameter as an unsigned 32-bit value; allowed range:
dependent on the selection made via
identical with set_vector_control
(see the comments there).
®
®
4 compatibility mode. The original RTC
set_vector_control
(Value parameter)
5 multiplies the specified coordinate values by 16
para_mark_rel_3d
(Ctrl parameter),
®
5 units
