4.4.4 MARKING ON THE FLY
Connector
The MARKING ON THE FLY connector provides,
among other things, encoder inputs for incorpo-
rating encoder signals. Together with the optional
Processing-on-the-fly-functionality, this enables laser
material processing of moving workpieces (e.g. on a
moving conveyer belt or rotating disk, see
The pin-out is shown in figure
+5 V (1)
ENCODER X1 – (3)
ENCODER X2 – (5)
ENCODER Y1 – (7)
ENCODER Y2 – (9)
/STOP2 (11)
BUSY OUT (13)
GND (15)
Pin-out of the (on-board) MARKING ON THE FLY connector

Encoder Inputs

®
The RTC 5 provides two encoder inputs ENCODER X
and ENCODER Y. Each of the encoder inputs are
designed for a pair (1, 2) of standardized RS422
differential signals (also see

External Control Signals

The external control signals /START2 and /STOP2
(TTL active-low) are referenced to PC ground (GND).
Both input signals are connected internally to +5 V
via pull-up resistors. Refer to the section
Stopping Lists via External Control Signals and
Master/Slave Synchronization", page

Analog Output Port

The 12-bit analog output port ANALOG OUT2 at
pin (14) is identical to the ANALOG OUT2 output port
at the LASER connector (see
to PC ground (GND).

BUSY Status

The BUSY OUT signal at pin (13) is identical to the
BUSY OUT signal at the LASER connector (see
page 46). The signal is referenced to GND.
®
RTC 5 PC Interface Board
Rev. 1.9 e
4 Layout and Interfaces
page 177).
18.
(2) GND
(4) ENCODER X1+
(6) ENCODER X2+
(8) ENCODER Y1+
(10) ENCODER Y2+
(12) /START2
(14) ANALOG OUT2
(16) NOT CONNECTED
18
page 215).
"Starting and
209.
page 47). It is referenced

Slot Cover (Optional)

SCANLAB recommends using an additional slot cover
for using the inputs and signals of the
MARKING ON THE FLY connector. A suitable slot
cover with a 15-pin D-SUB connector is available from
SCANLAB. Figure 19 shows the pin-out of this D-SUB
connector.
+5 V (1)
ENCODER X1 – (2)
ENCODER X2 – (3)
ENCODER Y1 – (4)
ENCODER Y2 – (5)
/STOP2 (6)
BUSY OUT (7)
GND (8)
Pin-out of the 15-pin female D-SUB connector of the optional
MARKING ON THE FLY slot cover

4.4.5 RS232 Interface

The "RS232" connector provides an RS232 interface
for controlling external equipment. The pin-out is
shown in figure 20.
Max. input voltage range: –25 V ... +25 V
Max. output voltage range: –13 V ... +13 V
The signals are referenced to PC ground GND.
NOT CONNECTED (1)
RxD (3)
TxD (5)
NOT CONNECTED (7)
GND (9)
Pin-out of the (on-board) "RS232" connector
The command rs232_config
baud rate (default setting: 9600 baud). The other
parameters cannot be altered (data bits: 8,
start bits: 1, stop bits: 1, parity: none). For
programming signal output and input via the RS232
interface, see page 207 and
(9) GND
(10) ENCODER X1+
(11) ENCODER X2+
(12) ENCODER Y1+
(13) ENCODER Y2+
(14) /START2
(15) ANALOG OUT2
19
(2) NOT CONNECTED
(4)  (6)
(6)  (4)
(8) NOT CONNECTED
(10) NOT CONNECTED
20
can be used to set the
page 208.
