Undelayed if_fly_x_overflow
Short
List Command
Function Conditional command execution for Processing-on-the-fly applications: This command
immediately executes the directly subsequent list command if the condition in accordance
with Mode for the X axis was fulfilled. Otherwise, the next list command is skipped over.
Call
if_fly_x_overflow( Mode )
Parameters
Mode
Comments • For command usage, see
• The error bits queried in accordance with Mode (error bit#4 and/or error bit#5) will be
reset.
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 525, OUT 527
References get_marking_info, set_fly_limits, clear_fly_overflow,
Undelayed if_fly_y_overflow
Short
List Command
Function Conditional command execution for Processing-on-the-fly applications: This command
immediately executes the directly subsequent list command if the condition in accordance
with Mode for the Y axis was fulfilled. Otherwise, the next list command is skipped over.
Call
if_fly_y_overflow( Mode )
Parameters
Mode
Comments • For command usage, see
• The error bits queried in accordance with Mode (error bit#6 and/or error bit#7) will be
reset.
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 525, OUT 527
References get_marking_info, set_fly_limits, clear_fly_overflow,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
To-be-evaluated condition as a signed 32-bit value:
= 0: Some kind of boundary exceedance occurred
(error bit#4 = 1 or error bit#5 = 1).
> 0: An overflow occurred (error bit#5 = 1).
< 0: An underflow occurred (error bit#4 = 1).
page 190.
To-be-evaluated condition as a signed 32-bit value:
= 0: Some kind of boundary exceedance occurred
(error bit#6 = 1 or error bit#7 = 1).
> 0: An overflow occurred (error bit#7 = 1).
< 0: An underflow occurred (error bit#6 = 1).
page 190.
if_not_fly_x_overflow
if_not_fly_y_overflow
