Ctrl Command set_auto_laser_params
Function specifies the automatic laser control's to-be-controlled signal parameter, the 100% value
and its corresponding limit values.
Call
set_auto_laser_params( Ctrl, Value, MinValue, MaxValue)
Parameters
Ctrl
Value
MinValue
MaxValue
Comments • For information on using the command, see
• The parameter's meaning is identical to that of the command
(also see comments there). However, set_auto_laser_params can neither start nor
terminate automatic laser control.
• If the value for Ctrl is invalid (0 or >6), then set_auto_laser_params will not be
executed
® ®
RTC 4 RTC 5 new command
®
RTC 4 compatibility mode: see
Version info Available beginning with version DLL 517, OUT 516, RBF 512
References set_auto_laser_control
Delayed Short set_auto_laser_params_list
List Command
Function same as
Call
set_auto_laser_params_list( Ctrl, Value, MinValue, MaxValue)
Parameters
Ctrl
Value
MinValue
MaxValue
Comments • If the value for Ctrl is invalid (0 or >6), then set_auto_laser_params_list is replaced
with a
® ®
RTC 4 RTC 5 new command
®
RTC 4 compatibility mode: see
Version info Available beginning with version DLL 517, OUT 516, RBF 512
References set_auto_laser_params,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
specifies the to-be-controlled signal parameter (see set_auto_laser_control);
allowed values: [1 ... 6]
100% value (see set_auto_laser_control)
lower range limit (see set_auto_laser_control)
upper range limit (see set_auto_laser_control)
(get_last_error return code: RTC5_PARAM_ERROR).
set_auto_laser_control
set_auto_laser_params (see above), but a list command
specifies the to-be-controlled signal parameter (see set_auto_laser_control);
allowed values: [1 ... 6]
100% value (see set_auto_laser_control)
lower range limit (see set_auto_laser_control)
upper range limit (see set_auto_laser_control)
list_nop (get_last_error return code RTC5_PARAM_ERROR).
set_auto_laser_control
set_auto_laser_control
"Automatic Laser Control", page
set_auto_laser_control
140.
