Ctrl Command set_softstart_mode
Function switches softstart mode on or off.
Call
set_softstart_mode( Mode, Number, Delay )
Parameters All parameters are unsigned 32-bit values.
Parameter
Mode
Number
Delay
Comments • The command set_softstart_mode must be called before first-time use of the
set_softstart_level
analog voltage values (default setting for softstart value handling: Mode = 3).
• The individual softstart values Level(0) – Level(Number – 1) must be provided individ-
ually via separate calls of set_softstart_level. Indices for which no Level value was
supplied are undefined.
• If the values for Mode or Number are invalid, then softstart mode will be switched off.
• When softstart mode is switched off, the already transmitted values are not deleted and
can be further used after a renewed switch-on. Here, you shouldn't unintentionally
switch between analog voltage values (Mode = 1, 2, 11 or 12) and pulselenghts (Mode
= 3 or 13). In contrast, you can switch at any time between ANALOG OUT1 (Mode = 1
or 11) and ANALOG OUT2 (Mode = 2 or 12).
• The softstart mode is incompatible with the pixel mode (see
set_softstart_mode will be executed, but softstart will not be executed while pixel
mode is operational.
• The softstart mode should not be used in conjunction with automatic laser control (see
page
ANALOG OUT1 or ANALOG OUT2 output ports or pulse lengths (PulseLength) or
output periods (HalfPeriod) of the laser signals LASER1 and LASER2.
Softstart mode cannot be combined with "freely definable wobbel shapes". If one is
defined and activated, the command will have no effect.
• Observe the notes in the section
® ®
RTC 4 RTC 5 essentially unchanged functionality (except for the extended range of values)
Instead of acquiring analog softstart values with the trailing edge of the laser signal pulse
(as achievable in the RTC
used as a trigger signal for realizing phase-shifted data acquisition with the RTC
notes in the section
under any circumstances.
Version info Last change with version OUT 515
References set_softstart_level, set_softstart_level_list,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
Allowed Values Description
= 0 disables the softstart mode, but does not remove previously loaded
softstart values.
= 1, 11 the softstart values defined via
analog voltage values at the ANALOG OUT1 port.
= 2, 12 the softstart values defined via
analog voltage values at the ANALOG OUT2 port.
= 3, 13 the softstart values defined via
pulselenghts of the first
(neither in laser mode 4 nor in laser mode 6).
1 ... 1024 number of softstart values to be transmitted.
32
0 ... (2 –1) defines the time period for which the laser must have been switched off
(1 bit equals 10 µs) before softstart will be activated at the next switch-on.
command, particularly if softstart values are to be outputted as
140) if automatic laser control readjusts the 12-bit output values at the
"Softstart Mode" on page
®
4 with Mode = 1, 2 or 3), a 180° phase-shifted laser signal can be
"Softstart Mode" on page
set_softstart_level
set_softstart_level
set_softstart_level
Number
laser signal pulses at the LASER1 port
page 192). The command
135.
135). An index shift will no longer exist
set_softstart_mode_list
will be outputted as
will be outputted as
specify the
®
5 (see
