Variable select_cor_table_list
List Command
Function similar to
Call
select_cor_table_list( HeadA, HeadB )
Parameters
HeadA
HeadB
Comments • See select_cor_table (page
• Even though select_cor_table_list is a short list command, execution of the directly
following list command will be delayed by a few clock cycles due to the intermediate
jump to the corrected galvanometer position. The extent of this delay depends on the
assigned correction table's content for the current galvanometer position (e.g. (0|0)
after load_program_file); but it is at least 10 µs, even if the correction table doesn't
specify a correction.
® ®
RTC 4 RTC 5 new command
Version info Last change (with version DLL 533, OUT 534): the parameter's value range has been
increased to [0...4]
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
select_cor_table (see above), but a list command
= 0: turns off the signals for scan head A (primary scan head connector)
= 1...4: assigns correction table number HeadA to scan head A
(as an unsigned 32-bit value)
= 0: turns off the signals for scan head B (secondary scan head connector)
= 1...4: assigns correction table number HeadB to scan head B
(activation required)
(as an unsigned 32-bit value)
400).
(load_correction_file lets you load up to 4 correction files)
