Scanlab RTC 5 PC Interface Board Installation And Operation Manual page 458

Ctrl Command set_mcbsp_x
Function activates or deactivates X offset correction for online positioning via the McBSP interface.
Call
set_mcbsp_x( Scale )
Parameter
Scale
Comments • For online positioning, see
• With an McBSP input value of X
apply_mcbsp
XOffset (in bits) = Scale
XOffset values outside of [–524288 ... +524287] will be clipped to the boundaries as
long as Scale
• The McBSP interface can't be simultaneously used for both online positioning and
Processing-on-the-fly applications (see
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 524, OUT 526
References set_mcbsp_x_list, set_mcbsp_y, set_mcbsp_rot,
Undelayed set_mcbsp_x_list
Short
List Command
Function same as
Call
set_mcbsp_x_list( Scale )
Parameter
Scale
Comments • See set_mcbsp_x.
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 524, OUT 526
References set_mcbsp_x
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
Value as a 64-bit IEEE floating point number:
–26 26
2 < Scale < 2 : scaling factor (correction will be activated)
otherwise: correction will be deactivated
page
in
will function like set_offset( ..., XOffset, ... ), whereby
·
X
in
·
X doesn't exceed the value range ±2
in
set_mcbsp_x (see above), but a list command
See set_mcbsp_x.
165.
for the X offset correction, the command
31
.
page 166).
apply_mcbsp
458
