Ctrl Command set_auto_laser_control
Result error code as an unsigned 32-bit value:
0
1
2
3
4
5
Comments • For information on using the command, see
• MinValue and MaxValue will be automatically exchanged if MinValue > MaxValue; if necessary,
MinValue will be clipped to  Value and MaxValue clipped to  Value.
• The control data for position- and/or speed-dependent laser control will be exclusively derived
from the scan system data at the primary scan head connector and then also applied for the
secondary scan head connector (if that connector has been activated and a scan system is
attached). At the time the command is issued, the primary scan head connector must already
have been assigned a correction table, otherwise error code 1 will be returned and Ctrl will
be set to 0. If only the secondary scan head connector is being used and/or the scan system at
the primary scan head connector is shut off, then speed-dependent laser control will not func-
tion.
• For Mode = 2, a functioning iDRIVE
connector. If this is not the case, then error code 2 will be returned and Ctrlset to 0. If the
iDRIVE
connector and both axes will be set to "actual velocity" via
Only thereafter will the command be sent to the RTC
applied. As a result,
connector as long as this mode selection is in effect. For Mode = 0 or 1,
available without any restriction.
• Encoder-speed-dependent laser control (Mode = 5) will function even if no scan heads are
attached to the scan-head connectors at runtime. The Processing-on-the-fly option doesn't
need to be activated here either.
• If the values for Ctrl or Mode are invalid, then set_auto_laser_control will not be executed
(return value 3 or 4,
• Automatic laser control shouldn't be combined with the variable laser power of
set_multi_mcbsp_in.
® ®
RTC 4 RTC 5 new command
®
In RTC 4 compatibility mode for Ctrl = 1/2, the specified values for Value, MinValue and
MaxValue are internally multiplied by 4. For Ctrl = 4/5 in RTC
parameter values for Value, MinValue and MaxValue must be specified in units of 1/8 µs. They will
then be internally converted to 1/64 µs units (i.e. multiplied by 8). The permissible range of values
is correspondingly smaller.
References load_position_control,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
No error.
no primary scan head active
®
no iDRIVE scan system (intelliSCAN
active
invalid Ctrl value
Mode
invalid value
access denied (board locked, get_last_error
®
scan system has reacted, then the queried data type for the primary scan head
control_command
get_last_error
load_auto_laser_control
® ® ®
, intelliSCAN , intelliDRILL , intellicube
de
RTC5_ACCESS_DENIED
return code
"Automatic Laser Control", page
®
scan system must be attached to the primary scan head
control_command
®
5, whereby the other parameters will be
will be unavailable for the primary scan head
return code: RTC5_PARAM_ERROR).
®
4 compatibility mode, the
® ®
, intelliWELD , varioSCAN )
de
)
140.
(Data = 0506 ).
H
control_command is
