Caution!
• Carry out the installation in an area that
complies with Electro Static Discharge (ESD)
directives. When installing the board, also
comply with instructions supplied in your
controller's user manual.
• Do not touch the contacts of the board.
• Protect the board from humidity, dust, corrosive
vapors and mechanical stress.
Perform the following steps to install the
®
RTC 5 PC/104-Plus board in a PC/104 stack:
 Shut down the operating system and switch off
the controller. Disconnect the controller from the
mains.
 Disconnect all peripherals (e.g. monitor, mouse,
keyboard, printer etc.) from the controller.
 Place the controller on a work table that complies
with ESD directives.
 Remove the housing of the controller.
 Check whether a PC/104-Plus connector is
available on the CPU board and check the stack
height (a PCI stack can contain up to four PC/104-
Plus modules).
®
 Remove the RTC
5 PC/104-Plus board from the
antistatic bag. Do not touch the contacts of the
board.
 If you want to use the signals on the
®
RTC 5 PC/104-Plus board's SCANHEADS, LASER
and/or MULTI connectors, then attach the appro-
priate cables (connection cables should only be
attached to equipment after the RTC
Plus board is installed). All RTC
signals are described in
Interfaces", page 577.
®
RTC 5 PC Interface Board
Rev. 1.9 e
®
15 Appendix A: The RTC 5 PC/104-Plus Board
®
5 PC/104-
®
5 connectors and
chapter 15.2 "Layout and
®
 Insert the RTC
5 PC/104-Plus board in the desired
position (1 to 4) within the PC/104 stack:
– The position in the stack should correspond to
the stack address set via jumpers JP17+JP18
(see page 584). Also check the other jumper
settings.
– Check if components on the RTC
board collide with components on the CPU
board (or a neighboring module in the stack).
– If multiple synchronously-clocked
®
RTC 5 PC/104-Plus boards are to be used in a
PC/104 stack, then the RTC
boards must be connected pairwise with each
other via the MASTER and SLAVE connectors
and installed in adjacent stack positions (also
see "Master/Slave Synchronization", page
– Check the above information on stacking
PC/104-Plus modules.
– Check that the board's PCI and ISA connectors
are correctly connected to the CPU board or the
neighboring modules in the stack.
– Use screws or spacer bolts to attach the board
to the CPU board or neighboring modules in
the stack.
 Close the housing of the controller.
 Place the controller at its operational location and
connect all peripheral equipment.
 If necessary, connect one or more of the
®
RTC 5 PC/104-Plus board's connectors to the
scan system (using the XY2-100 converter, if
necessary), to the laser, a handling system or
other supplementary equipment of the overall
system.
 Check all connections and turn on the controller.
®
5 PC/104-Plus
®
5 PC/104-Plus
579).
