chapter 2.3 "Optional Functionality", page
activation, this connector outputs – depending on
the assigned correction tables (see above) – the same
signal types as the primary scan head connector.
Slot cover (Optional)
SCANLAB recommends using an additional slot cover
for connecting a second scan head or a Z axis. A
suitable slot cover with a 9-pin D-SUB connector –
with the same pin-out as the primary scan head
connector (see figure 4, page
SCANLAB.
®
RTC 5 PC Interface Board
Rev. 1.9 e
4 Layout and Interfaces
27). After

4.3.2 XY2-100 Converter (Optional)

SCANLAB's optional XY2-100 converter converts the
RTC
XY2-100-compliant signals (16 bit), and converts the
scan system's XY2-100 status signals into SL2-100-
compliant signals (see
The XY2-100 converter introduces a 10 µs runtime
latency to scan-system control. This runtime latency
can be compensated by increasing the LaserOn Delay
41) – is available from
and LaserOff Delay by 10 µs each (see
set_laser_delays, page
Figure 6
converter.
Dimensions of the XY2-100 converter
The XY2-100 converter's 9-pin D-SUB connector
should be directly plugged into the RTC
scan head connector or (via a short-as-possible 1:1
cable) connected to the corresponding pins of the
RTC
out, see
The XY2-100 converter's 25-pin D-SUB connector is
compatible with scan heads that provide an XY2-100
standard interface. The pin-out is shown in
page
®
5's SL2-100 control signals (20 bit) into
page 127).
442).
shows the dimensions of the XY2-100
34.5
9-pin male D-Sub
25-pin female D-Sub
56.5
®
5's secondary scan head connector (for the pin-
figure 4 and figure 5 on page
43.
Thickness
12.5
6
®
5's primary
41).
figure 7,
42
