Normal set_fly_y
List Command
Function activates Processing-on-the-fly correction for compensation of a linear workpiece-
movement in the Y direction (based on position values transferred to the RTC
encoder counter Encoder1) and sets the corresponding scaling factor. Encoder counter
Encoder1 may be reset (see comments).
Restriction If the Processing-on-the-fly option is not enabled, then the command terminates the
Processing-on-the-fly process (even though it couldn't have been activated).
Call
set_fly_y( ScaleY )
Parameter
Scale
Comments • For Processing-on-the-fly correction and determination of the scaling factor, see
"Processing-on-the-fly (Optional)", page
• If unallowed parameter values are supplied (e.g. for ScaleY = 0), then set_fly_y will not
activate a Processing-on-the-fly correction or will deactivate a Processing-on-the-fly
correction previously activated via set_fly_y (but will not deactivate any other
Processing-on-the-fly correction). The latter case leads to a jump (at jump speed) to the
endpoint of the most recently executed vector or arc command (without "set_fly_y"
Processing-on-the-fly correction).
• The various Processing-on-the-fly corrections can't be arbitrarily combined (see the
page
• For deactivating Processing-on-the-fly correction, see
• Via set_control_mode, bit#9 can be set in advance to specify whether encoder counter
Encoder1 should reset immediately via set_fly_y or only after the subsequent external
start trigger (i.e. via the subsequent external start signal or
simulate_ext_start_ctrl
simulate_ext_start,
set_control_mode, bit#2).
• You can also switch on set_fly_x/set_fly_y Processing-on-the-fly correction via the
activate_fly_xy
® ®
RTC 4 RTC 5 unchanged functionality (except for the extended range of values)
®
In RTC 4 compatibility mode, the RTC
permissible range of values is correspondingly reduced).
Version info Last change with version OUT 515
References fly_return, set_fly_x, get_encoder, set_fly_x_pos, set_fly_y_pos, activate_fly_xy,
set_fly_2d
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
scaling factor for the Y direction (encoder counter Encoder1) in bits/count
(as a 64-bit IEEE floating point value);
allowed range: 1/256  |ScaleY|  16000.0
178).
command, possibly postponed by a track delay set via
set_ext_start_delay
command.
177.
page 186.
simulate_ext_start
or set_ext_start_delay_list; also see
®
5 multiplies the specified scaling factor by 16 (the
®
5 via
or
