Ctrl Command simulate_ext_start_ctrl
Function causes a simulated external list start.
Call
simulate_ext_start_ctrl()
Comments • For external list starts, see
• If applicable, the start trigger for the list start occurs only after a track delay previously
set via set_ext_start_delay,
the internal encoder counter which was selected by these commands was counted up
(or down) by the specified track delay). Track delays are deactivated via initialization
(with load_program_file), via external list stops and via stop_execution. They can also
be deactivated with
simulate_ext_start_ctrl or via an external start signal, but whose execution was post-
poned according to the specified track delay, will be placed in a queue that accommo-
dates up to 8 starts. In contrast to simulate_ext_start, simulate_ext_start_ctrl does
not cancel the previous queue.
• A start trigger initiated via simulate_ext_start_ctrl or via an external start signal will
only trigger a list start if it doesn't coincide with the output of a list (otherwise, bit#11
of the
• The simulate_ext_start_ctrl command alone doesn't cause an encoder reset. But if
accordingly set with
simulate_ext_start_ctrl,
encoder reset if the start trigger is preceded by one of the Processing-on-the-fly
commands set_fly_x,
® ®
RTC 4 RTC 5 new command
Version info Available beginning with version DLL 515, OUT 514, RBF 512
References simulate_ext_start
Ctrl Command simulate_ext_stop
Function causes a simulated external list stop.
Call
simulate_ext_stop()
Comments • For external list stops, see
• simulate_ext_stop simultaneously halts the master board and all slave boards, but
stop_execution
® ®
RTC 4 RTC 5 new command
References simulate_ext_start, simulate_ext_start_ctrl,
®
