• For RTC5OUT.out version up to 525, zero-length timed
mark or arc commands behave like non-timed mark or
arc commands with a length of zero.
• For RTC5OUT.out versions up to 526, the behavior of
mark or arc commands with a length of zero is
independent of the laser control signals.

Polygon Delay

Between two successive mark or arc commands,
there is no need for a complete stop of the scanners.
Therefore the mark delay between two successive
mark or arc commands is replaced by a polygon delay
LaserOn
Delay
Set Position
Mark
Command
Scan head and laser control timing during a polyline with a constant polygon delay
®
RTC 5 PC Interface Board
Rev. 1.9 e
7 Basic Functions for Scan Head and Laser Control
– see
correspondingly smaller edgelevel was set via
set_delay_mode
page
The mark delay and the polygon delay can be set
independently. In addition, the RTC
the length of the polygon delay, depending on the
angle between two marking vectors or the tangents
of the arcs. For details, see the section
Polygon Delay" on page
Real Position
Polygon Mark Polygon
Delay Command Delay
figure 33. Here, the laser remains on unless a
or set_delay_mode_list
104).
104.
LaserOff
Delay
…
Last Mark Mark Jump
Command Delay Command
In This Polyline etc.
(see
®
5 is able to vary
"Variable
Time
33
103
