Variable

activate_fly_xy

List Command
Function activates a
Restriction If the Processing-on-the-fly option is not enabled, then the command terminates the
Processing-on-the-fly process (even though it couldn't have been activated).
Call
activate_fly_xy( ScaleX, ScaleY )
Parameters
ScaleX,
ScaleY
Comments • If no Processing-on-the-fly correction is active, then activate_fly_xy will activate
set_fly_x/set_fly_y
activate_fly_xy doesn't thereby reset the encoders, but instead recalculates the last
Processing-on-the-fly-uncorrected coordinate values such that the Processing-on-the-
fly-corrected output matches the current output. If the then-current recalculated coor-
dinate values would have fallen outside the 24-bit virtual image field, then Processing-
on-the-fly correction won't be activated and an error bit will be set that is queryable via
get_marking_info
• If Processing-on-the-fly correction is active, then activate_fly_xy will be a short list
command without further effect and merely sets an error bit queryable via
get_marking_info
Processing-on-the-fly mode or the scaling factors of the same mode
• You can also query the error bit via the short list command
to possibly jump to an appropriate error handling routine.
• Successful activation via activate_fly_xy doesn't reset any already-set error bit. It will
remain set for
• If unallowed parameter values are supplied (e.g. for ScaleX = 0), then activate_fly_xy
will (already during loading) be replaced by a
RTC5_PARAM_ERROR).
• activate_fly_xy doesn't affect the laser signals ("laser active" laser control signals will
remain on/off if they were on/off).
® ®
RTC 4 RTC 5 new command
®
RTC 4 compatibility mode: see
Version info Available beginning with version DLL 536, OUT 536
References set_fly_x,
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
set_fly_x/set_fly_y Processing-on-the-fly application without encoder resets
Scaling factors as for set_fly_x/set_fly_y
Processing-on-the-fly correction. Unlike set_fly_x, and set_fly_y,
(bit #9 = 1).
(bit #9 = 1). Therefore, activate_fly_xy can't be used to modify the
get_marking_info until
set_fly_x/set_fly_y
set_fly_y
if_not_activated
get_marking_info is called.
list_nop (get_last_error
in order
return code
229
