Ctrl Command set_angle
Function
uses a specified rotation angle to define the rotation matrix M
coordinate transformations (see
Call
set_angle( HeadNo, Angle, at_once )
Parameters
HeadNo
Angle
at_once
Comments
• See
"Coordinate Transformations", page
®
®
RTC
4 RTC
5 new command
Version info
Last change with version DLL 525, OUT 527: behavior for at_once = 3
References
set_angle_list, set_matrix, set_offset,
®
RTC
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
"Coordinate Transformations", page
Number of the scan head connector as an unsigned 32-bit value:
= 1:
The definition only affects the primary scan head connector.
= 2:
The definition only affects the secondary scan head connector
(activation required)
= 0, 3: The definition affects both scan head connectors.
Only the two least significant bits are evaluated.
Rotation angle in ° (as a 64-bit IEEE floating point value); positive angles result
in a counterclockwise rotation around the centerpoint of the image field.
This parameter (unsigned 32-bit value) determines when the defined
transformation becomes effective:
= 0:
The new total transformation (total matrix and offset) is only
calculated and applied to the current position when the next list
command is executed.
= 1:
The new total transformation is calculated immediately (or before the
next list command if a list is currently BUSY or the board is INTERNAL-
BUSY) and applied to the current position. The "laser active"
laser control signals will first be switched off if necessary.
= 2:
The new total transformation (total matrix and offset) is only
calculated and applied to the current position when the next
jump_abs, jump_rel,
= 3:
As with at_once = 1, but the laser control signals remain unaffected.
> 3:
See at_once = 2
for all subsequent
R
goto_xy
or
goto_xyz
command is executed.
161.
set_scale
161).
405
