Ctrl Command set_extstartpos
Function defines the start address (within the range of "List 1" or "List 2") where execution should
continue upon subsequent external list starts.
Call
set_extstartpos( Pos )
Parameter
Pos
Comments • By default, an external list start results in a continuation or start at the beginning of
"List 1" (Pos = 0).
• Pos must be within the range of "List 1" or "List 2". Otherwise, Pos = 0 will be set.
• The specified start address will be used for all subsequent external list starts until a new
address is specified via set_extstartpos or set_extstartpos_list. An address range
validity check is performed on Pos before each external list start; Pos might therefore
become set to 0 at a later point (and remain at this value) if the configuration was corre-
spondingly changed in the meantime (see config_list).
• Also see
® ®
RTC 4 RTC 5 unchanged functionality (except for the extended range of values)
(the command was previously only available for the RTC
standalone version of the RTC
References set_extstartpos_list,
Undelayed set_extstartpos_list
Short
List Command
Function same as
Call
set_extstartpos_list( Pos )
Parameter
Pos
Comments • This list command can be used within a list, to "link" the current list to the next list.
• See set_extstartpos.
® ®
RTC 4 RTC 5 unchanged functionality (except for the extended range of values)
References set_extstartpos
®
RTC 5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
absolute address of the first list command to be executed as an unsigned
32-bit value; allowed range: [0 ... (2
"External List Start", page
®
4 board)
set_control_mode
set_extstartpos (see above), but a list command
absolute address of the first list command to be executed as an unsigned
32-bit value; allowed range: [0 ... (2
20
–1)]
210.
®
SCANalone Board, i.e. the
20
–1)]
