Reset and clock control (RCC)

Low-power modes

AHB and APB peripheral clocks, including DMA clock, can be disabled by software.

Sleep and LPSleep modes stop the CPU clock. The memory interface clocks (Flash

memory and SRAM1/2 interfaces) can be stopped during Sleep mode by software using the

SRAMxSMEN bits. The AHB to APB bridge clocks are disabled by hardware during Sleep

mode when all the clocks of the peripherals connected to them are disabled in the

peripheral SMEN bits.

Stop modes (Stop 0, Stop 1 and Stop 2) stop most clocks in the V

the PLLs, the MSI and the HSE32 oscillators. HSI16 may be kept running when requested

by the peripheral (USART1, USART2, LPUART1, I2C1, I2C2 or I2C3) that allows the

wakeup from Stop modes.

All U(S)ARTs, LPUARTs and I2Cs have the capability to enable the HSI16 oscillator even

when the MCU is in Stop mode (if HSI16 is selected as clock source for that peripheral).

All U(S)ARTs, LPUARTs and LPTIMs can also be driven by the LSE oscillator when the

system is in Stop mode (if LSE is selected as clock source for that peripheral) and the LSE

oscillator is enabled (LSEON). In that case, LSE remains always on in Stop mode (no

capability to turn on the LSE oscillator).

All LPTIMs can also be driven by the LSI oscillator when the system is in Stop mode (if LSI

is selected as clock source for that peripheral) and the LSI oscillator is enabled (LSION).

Standby and Shutdown modes stop all clocks in the V

HSI16, the MSI and the HSE32 oscillators.

The low-power modes can be overridden for debugging the CPU1 by setting the

DBG_SLEEP, DBG_STOP or DBG_STANDBY bits in the DBGMCU_CR register. In

addition, the EXTI CDBGPWRUPREQ events can be used to allow debugging the CPUs in

Stop modes (see the table below).

RM0453 Rev 1

domain and disable

domain and disable the PLL, the
