RM0453
38.11.9
TPIU claim tag clear register (TPIU_CLAIMCLR)
Address offset: 0xFA4
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 CLAIMCLR[3:0]: resets claim tag bits
Write:
0000: No effect
xxx1: Clears bit 0.
xx1x: Clears bit 1.
x1xx: Clears bit 2.
1xxx: Clears bit 3.
Read: Returns current value of claim tag.
38.11.10 TPIU device configuration register (TPIU_DEVIDR)
Address offset: 0xFC8
Reset value: 0x0000 0CA0
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:12 Reserved, must be kept at reset value.
Bit 11 SWONRZ: indicates whether serial-wire output, NRZ, is supported
1: Supported
Bit 10 SWOMAN: indicates whether serial-wire output, Manchester encoded format, is supported
1: Supported
Bit 9 TCLKDATA: indicates whether trace clock plus data is supported
0: Supported
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
Res.
Res.
Res.
Res.
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
SWON
SWOM
TCLKD
RZ
AN
ATA
r
r
r
RM0453 Rev 2
23
22
21
Res.
Res.
Res.
8
7
6
5
Res.
Res.
Res.
23
22
21
Res.
Res.
Res.
8
7
6
5
CLKRE
FIFOSIZE[2:0]
LAT
r
r
r
r
Debug support (DBG)
20
19
18
17
Res.
Res.
Res.
Res.
4
3
2
1
Res.
CLAIMCLR[3:0]
rw
rw
rw
20
19
18
17
Res.
Res.
Res.
Res.
4
3
2
1
MAXNUM[4:0]
r
r
r
r
16
Res.
0
rw
16
Res.
0
r
