By using the parameter
level-sensitive or edge-triggered:
• When using level-sensitive interrupts, the
MicroBlaze has taken the interrupt, and jumped to the interrupt vector. Software must
acknowledge the interrupt at the source to clear it before returning from the interrupt
handler. If not, the interrupt is taken again, as soon as interrupts are enabled when
returning from the interrupt handler.
• When using edge-triggered interrupts, MicroBlaze detects and latches the
input edge, which means that the input only needs to be asserted one clock cycle. The
interrupt input can remain asserted, but must be deasserted at least one clock cycle
before a new interrupt can be detected. The latching of an edge-triggered interrupt is
independent of the IE bit in MSR. Should an interrupt occur while the IE bit is 0, it will
immediately be serviced when the IE bit is set to 1.
With periodic interrupt sources, such as the FIT Timer IP core, that do not have a method to
clear the interrupt from software, it is recommended to use edge-triggered interrupts.
Low-latency Interrupt Mode
A low-latency interrupt mode is available, which allows the Interrupt Controller to directly
supply the interrupt vector for each individual interrupt (using the
input port). The address of each fast interrupt handler must be passed to the Interrupt
Controller when initializing the interrupt system. When a particular interrupt occurs, this
address is supplied by the Interrupt Controller, which allows MicroBlaze to directly jump to
the handler code.
With this mode, MicroBlaze also directly sends the appropriate interrupt acknowledge to
the Interrupt Controller (using the
responsibility of the Interrupt Service Routine to acknowledge level sensitive interrupts at
the source.
This information allows the Interrupt Controller to acknowledge interrupts appropriately,
both for level-sensitive and edge-triggered interrupt.
To inform the Interrupt Controller of the interrupt handling events,
• 01: When MicroBlaze jumps to the interrupt handler code,
• 10: When the RTID instruction is executed to return from interrupt,
• 11: When MSR[IE] is changed from 0 to 1, which enables interrupts again.
The
Interrupt_Ack
MicroBlaze Processor Reference Guide
UG984 (v2018.2) June 21, 2018
C_INTERRUPT_IS_EDGE
Interrupt_Ack
output port is active during one clock cycle, and is then reset to 00.
www.xilinx.com
Chapter 2: MicroBlaze Architecture
, the external interrupt can either be set to
input must remain set until
Interrupt
Interrupt_Address
output port), although it is still the
Interrupt_Ack
Interrupt
is set to:
