Latency
• 1 cycle with
• 2 cycles with
Notes
The byte reversed instruction is only valid if MicroBlaze is configured to use reorder instructions
(C_USE_REORDER_INSTR = 1).
The extended address instruction is only valid if MicroBlaze is configured to use extended address
(C_ADDR_SIZE > 32).
