Xilinx PCI32 Specifications

co.com
DS206 August 31, 2005
Features
• Fully PCI 3.0-compliant LogiCORE™, 32-bit, 66/33
MHz interface
• Customizable, programmable, single-chip solution
• Pre-defined implementation for predictable timing
• Incorporates Xilinx Smart-IP™ technology
• 3.3V operation at 0-66 MHz
• 5.0V operation at 0-33 MHz
• Fully verified design tested with Xilinx proprietary
testbench and hardware
• Available through the Xilinx CORE Generator™
v7.1i or higher
• CardBus compliant
• Supported initiator functions:
- Configuration read, configuration write
- Memory read, memory write, MRM, MRL
- Interrupt acknowledge, special cycles
- I/O read, I/O write
• Supported target functions:
- Type 0 configuration space header
- Up to three base address registers (MEM or I/O
with adjustable block size from 16 bytes to 2 GB)
- Medium decode speed
- Parity generation, parity error detection
- Configuration read, configuration write
- Memory read, memory write, MRM, MRL
- Interrupt acknowledge
- I/O read, I/O write
- Target abort, target retry, target disconnect
