getd get from stream interface dynamic
rD, rB
tneagetd
tnecagetd rD, rB
0 1 0 0 1 1
0
6
Description
MicroBlaze will read from the interface defined by the four least significant bits in rB and place the
result in register rD. If the available number of links set by C_FSL_LINKS is less than or equal to the
four least significant bits in rB, link 0 is used.
The getd instruction has 32 variants.
The blocking versions (when 'n' bit is '0') will stall MicroBlaze until the data from the interface is valid.
The non-blocking versions will not stall MicroBlaze and will set carry to '0' if the data was valid and to
'1' if the data was invalid. In case of an invalid access the destination register contents is undefined.
All data get instructions (when 'c' bit is '0') expect the control bit from the interface to be '0'. If this is
not the case, the instruction will set MSR[FSL] to '1'. All control get instructions (when 'c' bit is '1')
expect the control bit from the interface to be '1'. If this is not the case, the instruction will set
MSR[FSL] to '1'.
The exception versions (when 'e' bit is '1') will generate an exception if there is a control bit mismatch.
In this case ESR is updated with EC set to the exception cause and ESS set to the link index. The target
register, rD, is not updated when an exception is generated, instead the data is stored in EDR.
The test versions (when 't' bit is '1') will be handled as the normal case, except that the read signal to
the link is not asserted.
Atomic versions (when 'a' bit is '1') are not interruptible. This means that a sequence of atomic
instructions can be grouped together without an interrupt breaking the program flow. However, note
that exceptions might still occur.
When MicroBlaze is configured to use an MMU (C_USE_MMU >= 1) and not explicitly allowed by
setting C_MMU_PRIVILEGED_INSTR to 1 these instructions are privileged. This means that if these
instructions are attempted in User Mode (MSR[UM] = 1) a Privileged Instruction exception occurs.
