Introduction
The MicroBlaze™ Processor Reference Guide provides information about the 32-bit soft
processor, MicroBlaze, which is included in Vivado. The document is intended as a guide to
the MicroBlaze hardware architecture.

Guide Contents

This guide contains the following chapters:
• Chapter 2, MicroBlaze Architecture
as information on Big-Endian and Little-Endian bit-reversed format, 32-bit general
purpose registers, cache software support, and AXI4-Stream interfaces.
• Chapter 3, MicroBlaze Signal Interface Description
interfaces that can be used to connect MicroBlaze.
• Chapter 4, MicroBlaze Application Binary Interface
Interface important for developing software in assembly language for the processor.
• Chapter 5, MicroBlaze Instruction Set Architecture
instructions for the Instruction Set Architecture (ISA) of MicroBlaze.
• Appendix A, Performance and Resource Utilization
resource utilization numbers for different configurations and devices.
• Appendix B, Additional Resources and Legal Notices
and additional resources.
MicroBlaze Processor Reference Guide
UG984 (v2018.2) June 21, 2018
contains an overview of MicroBlaze features as well
describes the types of signal
describes the Application Binary
provides notation, formats, and
contains maximum frequencies and
provides links to documentation
