Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
8.5.11

Modem Information

Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command Query
Hardware Revision N/A HRV?
Software Revision N/A SWR?
Firmware N/A FRW?1
information FRW?2
FRW?B
Serial Number N/A SNO?
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
4 bytes Query only.
Return hardware revision level of both main circuit cards in the form xx.yy where:
xx=the main (bottom) card
yy=the top (modem) card.
62 bytes Query only.
Returns the value of the internal software revisions installed in the unit, see example below.
EXAMPLE: <0/SWR?
>0000/SWR=Boot:01.01.01 AppLoader:01.01.01 Bulk1:01.01.01 Bulk2:01.01.01
434 or 74 bytes Query only.
Returns firmware information for image 1 or 2 or the boot loader in the form xxxxxx, where:
EXAMPLE 1: <0/FRW?1
>0000/FRW=1:FW-0020628- 1.1.1 03/22/13<CR>
FW-0020628- 1.1.1 03/22/13<CR>
FW-0020638- 1.1.1 10/24/12<CR>
FW-0020639- 1.1.1 02/28/13<CR>
FW-0020638- 1.1.1 01/28/13<CR>
FW-0020529- 1.1.1 01/09/13<CR>
FW-0020531- 1.1.1 01/21/13<CR>
FW-0020532- 1.1.1 12/18/12<CR>
FW-0020649- 1.1.1 12/17/12<CR>
FW-0020530- 1.1.1 01/09/13<CR>
FW-0020641- 1.1.1 03/20/13<CR>
FW-0020307C 1.1.4 08/26/11<CR>
FW-0020308B 1.3.2 02/19/13<CR>
FW-0020309B 1.3.2 01/31/13<CR>
FW-0020372D 1.2.3 02/14/13<CR>
FW-0020468C 1.1.4 02/26/13<CR>
EXAMPLE 2: <0/FRW?B
>0000/FRW=B:Boot: FW-0020640- 1.1.1 02/13/13<CR>
App Loader: FW-0020629- 1.1.1 02/08/13<CR>
9 bytes Query only.
Returns the modem 9 digit serial number.
EXAMPLE: <0/SNO?
>0000/SNO=176500143
8–37
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
HRV# HRV=xx.yy
SWR# SWR=Boot:xx.x
x.xx
AppLoader:xx.x
x.xx
Bulk1:xx.xx.xx
Bulk2:xx.xx.xx
FRW? FRW=
FRW#
SNO# SNO=xxxxxxxxx
