CDM-570/570L Satellite Modem with Optional IP Module
Appendix K
PS: +5V=5.5
This read-only screen shows a monitor for the remaining two internal power supplies.
K.3.3.1.1.1.1.4 ODU SELECT: Alarms
ALARMS: Current
Use the ◄ ► arrow keys to select Current or Stored, and then press ENTER.
(ODU SELECT) ALARMS: Current
TX = OK
PWR SUP = OK
This read-only screen summarizes the CSAT's current status. If any of the items display
"FT" instead of "OK" then that feature is faulted – view the Stored Events Log for further
details.
(ODU SELECT) ALARMS: Stored
Stored Events:
Clear All
Use the ◄ ► arrow keys to select View or Clear All, and then press ENTER.
(ODU SELECT) ALARMS: Stored
LOG 02:11/13/99 10:42:47
OK- REF
Per the example shown, use the ▲ ▼ arrow keys to sequentially view the individual
entries in the Stored Events Log, and then press CLEAR to return to the previous menu.
(ODU SELECT) ALARMS: Stored
PRESS ENT TO
CLEAR THE EVENTS LOG
Press ENTER to clear the Stored Events Log. Otherwise, press CLEAR to exit and
return to the previous menu.
-5V=-4.9
Stored
(◄ ►,ENT)
RX = OK
MISC = OK
View
(◄ ►,ENT)
LOCK (▲ ▼)
K–14
View
Clear All
Revision 12
MN/CDM570L.IOM
