CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
14.2.6

Protocol Configuration Page

Activate the Protocol Configuration Page from the Main Menu page.
The Protocol Configuration Page contains the following options/fields:
Selection
IGMP
ARP
DHCP Server IP Address
Brouter Mode

Figure 14-19. Protocol Configuration Page

Entry Description
I Displays the IGMP page.
A Displays the ARP Table Utilities page.
R Allows entry of the DHCP server IP address.
Allows hosts on a remote LAN to send DHCP request packets to the
DHCP server so that the DHCP server can dynamically assign IP
addresses to remote hosts.
B Displays the Brouter Configuration page.
14–30
Revision 12
MN/CDM570L.IOM
