SLM-5650A Satellite Modem
Appendix C
C.6.5 Bulk Configuration Commands / Queries
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Configuration CLD= 1 byte
Load
Configuration CST= 1 byte
Save
Global MGC= Command can
Configuration be 177 bytes or
217 bytes,
Query
Response is
always 217
bytes
Description of Arguments
Query
Command only.
Causes the modem to retrieve a previously stored configuration
from Configuration Memory location defined by the one-byte
argument (0 to 9).
Example: CLD=4 (retrieve modem configuration from location 4)
Command only.
Command causes the modem to store the current configuration in
Configuration Memory location defined by the one-byte argument
(0 to 9).
Example: CST=4 (store the current configuration in location 4)
Command or Query.
Global Configuration of SLM-5650A, in the form:
abcdeeeeeefghijabbbbbbklmnoooooo.ooopppp.ppppqcrestuvwxyyy.y
zABCDEFGHHff.fffIJKLLLLLL.LLLMMMM.MMMMNgggPQRSTUVW
XYZZZZ.ZZZAAABCDDDDDDDDEE.EFGHIJKLMNNN.NOOO.OPP
P.PQQ.QR.RSTUVWXXYZZhhhijjjkllllllllllllllllllllllllllllllll
a = Modem Operating Mode
b = Modem RF Band
c = Modem Interface Type
d = Modem Reference Clock
eeeeee = Modem Alarm Mask
f = Carrier Only Test Modes
g = Loopback Test Modes
h = Tx BERT State
i = Rx BERT State
j = BERT Pattern
a = CnC Mode
bbbbb = CnC Mode
k = expansion byte
l = Tx FEC Type
m = Tx Modulation Type
n = Tx Code Rate
oooooo.ooo = Tx Data Rate
pppp.pppp = Tx Frequency
q = Tx Overhead Type
c = NP Bridge Mode
r = expansion byte
e = NP Secure Mode
where:
same as MOM
same as RFB
same as ITF
same as MRC
same as MSK
same as COM
same as LOP
same as BTX
same as BRX
same as PAT
same as CNM
same as CSD
same as TFT
same as TMD
same as TCR
same as TDR
same as TFQ
same as TFM
same as GBM
same as MIS
C–29
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
CLD= N/A N/A
CLD?
CLD*
CLD#
CST= N/A N/A
CST?
CST*
CST#
MGC= MGC? MGC=abcdeeeeeefghijab
MGC? bbbbbklmnoooooo.oooppp
MGC* p.ppppqcrestuvwxyyy.yzA
MGC# BCDEFGHHff.fffIJKLLLLL
L.LLLMMMM.MMMMNggg
PQRSTUVWXYZZZZ.ZZZ
AAABCDDDDDDDDEE.E
FGHIJKLMNNN.NOOO.O
PPP.PQQ.QR.RSTUVWX
XYZZhhhijjjkllllllllllllllllllllllllllll
llll
(see Description of
Arguments)
