CDM-570A/570AL Satellite Modem with Optional Packet Processor
Ethernet-based Remote Product Management
Column
Index
VLAN Priority
Max Bw (kpbs)
WRED
Click [Submit Changes] to update the specified rule.
Make sure to also click [Save PaP Parameters] on the 'Admin | PaP Save' page before
proceeding further.
7.4.3.3.6.2

Configuration | WAN | Compression

Use this page to configure the optional Payload and Header Compression, when this FAST
feature is enabled.
Compression
•
Header Comp. Refresh Rate for UDP/RTP1 – Enter the number of packets, from 1 to 600,
required to trigger the Header Compression's User Datagram Protocol/Real Time Protocol
refresh rate.
•
Header Comp. Refresh Rate for UDP – Enter the number of packets, from 1 to 600, required
to trigger the Header Compression's User Datagram Protocol refresh rate.
• Header Comp. Refresh Rate for all others – Enter the number of packets, from 1 to 600,
required to trigger the Header Compression's Default Protocol refresh rate.
•
Payload Comp. Refresh Rate – Enter the number of packets, from 1 to 600, required to
trigger the Payload Compression's refresh rate.
Click [Submit] to save.
Make sure to also click [Save PaP Parameters] on the 'Admin | PaP Save' page before
proceeding further.
Description
This is the internal table index that is automatically assigned and cannot be edited.
Specifies the VLAN Priority established for the specific rule (0-7).
Specifies the Maximum Bandwidth value in kilobits per second.
Specifies the WRED (Weighted Random Early Detection) setting for the specific rule as Yes
or No.
Figure 7-22. Configuration | WAN | Compression page
7–47
MN-CDM570A
Revision 3
