Elevator Opto Sensor Remove and Replace

The Elevator Opto Sensor is mounted inside the chassis at the bottom of the Elevator opening.

Elevator Opto Sensor Removal

1) Using the Graphical User Interface (GUI), park the cartridge Shuttle Assembly by powering
off the module, see
the Shuttle Assembly Robotics for Service or Shipment".
2) Turn off the Master Power Switch on the power supply at the rear of the module.
3) Remove the power cord from the receptacle.
4) Remove the Tabletop Cover, Front Main Cover and Fan Cover Assembly using
Covers Remove and Replace"
5) Remove the Drive 1 Shoe Assembly using
instructions in this chapter.
6) Remove the screw from the Card Cage/Back Plane Connector Access Plate and lift it out of
the library, (Figure
7) Remove the two screws that mount the Elevator sensor to the chassis,
8) Remove the cable ties that secure the Elevator cable to the main wiring harness.
9) Disconnect the cable at J8 on the Card Cage/Back Plane PCB,
Figure 2–16. If the module is not operable, refer to the section "Parking
instructions in this chapter.
"Drive Shoe Assembly Remove and Replace"
2–22).
Figure 2–22. Access Plate Removal
E O S R
LEVATOR PTO ENSOR EMOVE AND
"Library
Neo-9054
(Figure 2–23).
(Figure 2–23).
Servicing the Neo Series 2000
R
EPLACE
2-23
