Elevator Opto Sensor Replacement; Figure 3-71 Pass Thru Sensor Remove - Overland Storage Neo Series Library Service Manual

E O S R
LEVATOR PTO ENSOR EMOVE AND

Elevator Opto Sensor Replacement

3-76 Servicing the Neo Series 4000
u
R
EPLACE
Figure 3–71. Pass Thru Sensor Remove
8) Remove the cable ties that secure the Elevator cable to the main wiring harness.
9) Disconnect the cable at J8 on the Card Cage/Back Plane PCB,
10) Carefully work the cable through the opening under the Card Cage and into the main chassis
area to remove the Elevator Opto Sensor.
1) Position the Elevator Opto Sensor in the mounting hole with the cable routed along the main
wiring harness to the left.
2) Replace the two snap rivets,
3) Replace the cable ties in the locations there were removed step (5) of the removal instruction.
4) Carefully work the cable through the opening under the left magazine track and into the
card/cage backplane area.
5) Feed the cable through and connect to J8,
6) Replace the Card.Back Plane Connector Access Plate and replace the screw,
7) Replace the Drive 1 Shoe Assembly using
instructions in this chapter.
J8
(Figure 3–71).
(Figure 3–71).
"Drive Shoe Assembly Remove and Replace"
Neo-0058
(Figure 3–71).
(Figure 3–70).
