Front Vertical Axis Assembly Remove and Replace

Removing the Front Vertical Axis Assembly

3-84
Servicing the Neo Series 4000
u
R
EMOVE AND
EPLACE
1) Power off the library using the front panel control and then switch the Master Power Switches
on the power supplies at the rear of the module to the off (0) position. Remove the power
cords.
2) Remove the Tabletop Cover and Front Chassis Cover of the module using the
Remove and Replace"
3) Manually rotate the robot track by turning the motor/track coupler approximately 90 degrees,
(Figure
3–79).
4) Depress the Shuttle brake lever on the bottom of the shuttle and slide the Robot Shuttle on the
track towards the rear of the unit
removal.
instructions in this chapter.
Figure 3–79. Rotate Track 90 Deg
(Figure
3–80). This step allows for easier Vertical Axis
"Library Covers
Neo-7001a
