Elevator Opto Sensor Remove and Replace

The Elevator Opto Sensor is mounted inside the chassis at the bottom of the Elevator opening.

Elevator Opto Sensor Removal

1) Using the Graphical User Interface (GUI), park the cartridge Shuttle Assembly by powering
off the module. If the module is not operable, refer to the section "Parking the Shuttle
Assembly Robotics for Service or Shipment".
2) Turn off the Master Power Switches on the power supplies at the rear of the module.
3) Remove the power cord from the receptacle.
4) Remove the Tabletop Cover, Front Chassis Cover and Fan Cover Assembly using
Covers Remove and Replace"
5) Remove Drive 1 Shoe Assembly using
instructions in this chapter.
6) Remove the screw from the Card Cage/Back Plane Connector Access Plate and lift it out of
the library, (Figure
7) Remove the two snap rivets that mount the Elevator sensor to the chassis, (Figure 3–71).
instructions in this chapter.
"Drive Shoe Assembly Remove and Replace"
3–70).
Figure 3–70. Backplane Access Cover
E O S R
LEVATOR PTO ENSOR EMOVE AND
Neo-9054a
Servicing the Neo Series 4000
R
EPLACE
"Library
3-75
