Front Panel Remove and Replace

The Front Panel assembly mounts on the front of the main chassis of the library. It includes a replaceable
Graphical User Interface (GUI), a replaceable Front Panel LED, and replaceable Front Panel Solenoids
for the left and right magazine door lock mechanisms. The Front Panel must be removed to replace the
GUI, Front Panel LED, and the Front Panel Solenoids.

Front Panel Removal

1) Using the GUI, open the magazine doors and remove the two magazines. If the module is not
operable, refer to
2) Using the GUI, park the cartridge Shuttle Assembly by powering off the module and then
switch the Master Power Switch at the rear of the module to the off (0) position. If the module
is not operable, refer to
3) Remove the power cord from the receptacle.
4) Remove the tabletop cover and front main cover using
instructions in this chapter.
5) Locate the Control Panel Printed Circuit Board (PCB) assembly in the bottom of the chassis
behind the front panel, see
Disconnect the zero insertion force cable at J15 by sliding-up the body of the connector to
release the flex cable. Remove the flex cable from the connector.
6) Open the magazine doors using the door release in the front of the panel. Refer to the section
"Emergency Magazine Removal"
"Emergency Magazine Removal"
"Parking the Shuttle Assembly Robotics for Service or
Figure 2–8. Disconnect the cables at J14, J16, J13 and J3.
.
J15
J16
J14
J13
Figure 2–8. Control Panel Board
if necessary.
F P R
RONT ANEL EMOVE AND
procedures.
"Library Covers Remove and Replace"
J3
Neo-9041
Servicing the Neo Series 2000
R
EPLACE
Shipment".
2-9
