Figure 2-6 Shuttle Brake Release; Figure 2-7 Shuttle Assembly In Parked Position - Overland Storage Neo Series Library Service Manual

P S A R
ARKING THE HUTTLE SSEMBLY
2-8 Servicing the Neo Series 2000
u
S S
OBOTICS FOR ERVICE OR HIPMENT
8) Release the brake release lever and verify that it is locked.
9) Replace the tabletop cover and front main cover using
instructions in this chapter if the library is to be shipped.
10) It is now safe to proceed with the service or shipment.
Stationary Track
Section
Figure 2–7. Shuttle Assembly in Parked Position
.
Figure 2–6. Shuttle Brake Release
.
Rotating Track
Section
Neo-9038
"Library Covers Remove and Replace"
Neo-9037
