Mail Slot Interlock

The Mail Slot Interlock Assembly is mounted on the underside of the upper and lower left magazines
track near the front of the library and locks both the magazines and the mail slots. The upper and /or
lower left magazines must be removed to remove the interlocks.

Mail Slot Interlock Removal

1) Remove the left magazine using the front panel control. Refer to the section
Magazine Removal"
2) Using the Graphical User Interface GUI, park the cartridge Shuttle Assembly by powering off
the module and then switch the Master Power Switches on the power supplies at the rear of the
module to the off (0) position. If the module is not operable, refer to the section
Shuttle Assembly Robotics for Service or
3) Unplug the power cords.
4) Remove the Tabletop Cover and Front Chassis Cover using
Replace" instructions in this chapter.
5) By releasing the brake on the Shuttle Assembly move it toward the rear of the Library. This
allows easier access to the lower cover plate mounting screws.
6) Remove the Control Panel PCB cover plate (four screws)
7) Disconnect the white cable(s) at J15 (Upper) and/or J18 (Lower) locations on the Control
Panel PCB, (Figure
NOTE: For easier cable accessibility, the PCB may be removed from the mounts on the front
side of the chassis. See
8) While supporting the interlock assembly below the magazine track, remove the two flat-head
mounting screws that are towards the center of the magazine track
NOTE: Early model Neo Series 4000 units may include shims under the mail slot latch bracket.
if necessary.
Shipment".
Figure 3–22. Control Panel PCB Cover Plate
3–20).
"Control Panel PCB Remove and
M S
AIL LOT
"Emergency
"Parking the
"Library Covers Remove and
(Figure 3–22).
Neo-0057
Replace".
(Figure 3–23).
Servicing the Neo Series 4000
I
NTERLOCK
3-25
