Number of
Modules
6
7
8
14) Thread the Timing Belt counter-clockwise through the top of the Tensioner Ramp/Idler Pulley
and clockwise through the motor drive pulley. See
Figure C–16. Timing Belt Installation Base Section
Figure C–17. Timing Belt Installation
Table C-1 Timing Belt Lengths
Number of Teeth Length of Belt
Centimeters
519 263.6
607 308.4
694 352.6
Figure C–16
E A E
LEVATOR SSEMBLY XTENSION
Length of
Belt Inches
103 13/16
121 3/8
138 13/16
and Figure C–17.
Neo-9112
Neo-9113
C-17
