Front Panel Door Latch Remove and Replace

The Front Panel Door Latch solenoids for the left and right magazine door lock mechanisms are mounted
on the inside of the Front Panel. The Front Panel must be removed to replace the Front Panel Door Latch
solenoids.

Front Panel Door Latch Removal

1) Using the Graphical User Interface (GUI), park the cartridge Shuttle Assembly by powering
off the module, see
the Shuttle Assembly Robotics for Service or Shipment".
2) Turn off the Master Power Switch on the power supply at the rear of the module.
3) Remove the power cord from the receptacle.
4) Remove the Front Panel using
5) Note the location of the cable tie that is near the left-hand door solenoid that ties the two
solenoid cables and the power LED cable together. Remove the cable tie.
6) Remove the two screws that mount the door latch solenoid to the Front Panel.
Figure 2–16. If the module is not operable, refer to the section "Parking
"Front Panel Remove and Replace"
.
Figure 2–16. Front Panel Solenoids Cable Tie
F P D L R
RONT ANEL OOR ATCH EMOVE AND
instructions in this chapter.
Neo-9045
Servicing the Neo Series 2000
R
EPLACE
2-17
