Figure 3–91. Access Panel / Flex Cable Bracket
b.Remove the two screws that secure the finger guard and fan to the standoffs
c.Remove the Card Cage Fan from the from the mounting standoffs.
NOTE: The fan need not be physically removed from the library or disconnected from the card
cage backplane. For example the fan may be temporarily secured out of the way by inserting a
small tie wrap through one of the fan mounting holes and attaching it to the rear lead screw.
Figure 3–92. Removing Fan from the Standoffs
4) Remove the library Front Panel of the module using the
instructions in this chapter.
R B F
OBOT ASE LEX
Neo-9163a
"Front Panel Remove and Replace"
Servicing the Neo Series 4000
C R R
ABLE EMOVE AND EPLACE
Neo-9055c
(Figure 3–92).
Neo-9055b
3-95
