Table 5-2 Fault Symptom Codes (Continued)
Message
The Scsi response was not expected
The Flash response was not expected
Scsi response not matched to a known
command
Unexpected state after NonVolConfig cmd
Unexpected state after SCSI mode cmd
Unexpected state after SCSI init cmd
Cartridge reject recovery failed
Drive Fan stalled
Drive load did not complete
Invalid drive was installed
Slto unmask drive failed
Slto mask drive failed
Slto unload drive(in load retry) failed
Is Drive Unloaded Failed
Orphan cartridge recovery failed
Master pass-thru opto failed.
SMX send error
FSC ERP
701F C,G The command response from the Scsi
task in a remote module was unexpected.
7020 C,G The command response from the Flash
task in a remote module was unexpected.
7021 C,G A command response was received from
a Scsi task, but the original command
opcode could not be determined.
7022 C,G After successfully completing a
NonVolConfigPut command, the current
state of the save operation was unknown.
7023 C,G After successfully completing a
ScsiUpdateModeParameters command,
the current state of the save operation
was unknown.
7024 C,G After successfully completing a
ScsiInitcommand, the current state of the
save operation was unknown.
8001 C,D,G The DLT drive failed to successfully load a
tape even after retries.
8002 C,D,G The fan in the drive hot-swap shoe is
either not installed or has stalled.
8003 C,D,G The drive failed to successfully load a
tape.
8004 F One or more installed drives are of a type
either unknown or not supported in the
current library personality.
8005 F The Seagate LTO drive unmask operation
failed.
8006 F The Seagate LTO drive mask operation
failed.
8007 F The Seagate LTO drive failed to unload a
cartridge during a load retry operation.
8008 F The Seagate LTO drive failed to return
status when being polled for unloaded
state.
9001 C,D,G The master module could not successfully
return an orphan cartridge to a slot
location.
9003 C,D,G The master module opto sensor was not
detected during the power-up pass-thru
module inventory.
A001 C,G An attempt to place a message on a task's
exchange generated a kernel error.
F S C (FSC )
AULT YMPTOM ODES S
Troubleshooting 5-11
